Suriname customer ordered a detachable gooseneck trailer two weeks ago. He saw our product information on Facebook and was interested in our detachable gooseneck semi trailers, so he contacted us. Our account manager gave a detailed introduction to the detachable gooseneck trailer's structure, performance, advantages, price and other aspects. In the end, the customer readily paid the deposit and spoke highly of our products and services.

The detachable gooseneck trailer for sale in Suriname Nickli is mainly used to transport heavy engineering machinery, such as excavators, bulldozers, loaders, pavers, cranes, etc. and other heavy-duty goods. The lower the center of gravity, the better the stability and safety, and the transportation is ultra-high. The higher the cargo and the greater the ability to pass overhead obstacles.

The detachable gooseneck trailer for sale in Suriname Nickli has a gooseneck that can be completely detached from the semi-trailer so that the front end of the semi-trailer is lowered to contact the ground but remains connected to the rear end of the tractor. After loading or unloading, the tractor drags the gooseneck back and aligns with the front end of the semitrailer. The semitrailer reconnects with the gooseneck and returns to the transport state.

The front end of the detachable gooseneck trailer for sale in Suriname Nickli is an inclined plane with a foldable slope on it. When the slope is turned down, it can be combined with the slope of the front end of the semi-trailer to form a slope required for loading and unloading mechanical equipment. The distance between the two foldable ramps ensures that when the gooseneck is connected to the semi-trailer, the gooseneck can enter the gap between the two without interference. This foldable ramp prevents the tractor from interfering with the ramp. At the front end of the semi-trailer, a pair of forward protruding pins are fixed below the cargo platform plane. The pins can be smoothly connected to the orifice plate on the base of the gooseneck under the joint action of the guide pin and the guide plate.

(1) Operation process of detachable gooseneck trailer

When disassembling the gooseneck, first separate the detachable gooseneck trailer's front hinge from the tractor seat. During actual operation, the front part of the gooseneck may slip off. As the gooseneck continues to lower, the bottom corner of the front trailer will gradually approach the ground. After the detachable gooseneck trailer for sale in Suriname drives for a period of time, the weight of the trailer will be reduced, and part of the weight will be shared with the front end of the detachable gooseneck trailer wheel for support. However, most of the goosenecks are in a cantilevered state, which can make the front end of the trailer extend outward.

After completing the disassembly, remove the retaining ring and move it forward until the retaining ring can be connected to the connecting plate so that the pin can be completely separated from the detachable gooseneck trailer. Then, place the retaining ring at the rear of the trailer and connect it to the steel belt. At this time, the rotating handle should be contracted as much as possible and kept in a low clockwise running direction. The tractor can then move backwards. The gooseneck bow structure can slide back and forth on the pulling plane. Under continuous rotation operation, the tractor can move backwards. The tooth-shaped raised parts are smoothly separated from the grooves

As the tractor continues to move forward, in view of the fact that the gooseneck and the traction seat are connected to each other, the tractor at this time is in a state of separation from the detachable gooseneck trailer. The semi-trailer will continue to operate. Tend to a tilted state.

After completing the loading of the detachable gooseneck trailer, the above operations can be reversed and repeated. The tractor can continuously pull the gooseneck backward, so that the gooseneck finally stops at the front end of the detachable gooseneck trailer for sale in Suriname Nickli. At this time, the detachable gooseneck trailer's rocker handle can be inserted into the spring position and continuously bounced to the top position, and the tractor can continue to move toward the detachable gooseneck trailer for sale in Suriname Nickli. The rear movement causes the upper guide ramp of the detachable gooseneck trailer to push the gooseneck lug back to the standard position.

As the protruding rod continues to move backward, the shaft pin can rise from the rear and gradually bulge. The bulging tappet can always be in the prescribed position and the gooseneck is orthogonally connected to the detachable gooseneck trailer to form a whole. Subsequently, the gooseneck and the traction tilt seat will be separated from each other and moved forward by the tractor. As the tractor continues to move, the gooseneck will always move along the inclined surface in a repeated convex motion.

Therefore, the slippage of the front end of the gooseneck can prompt the gooseneck to always rotate and move around the protruding rod area. During the whole process, the tooth-shaped protrusions will be inserted into the slot again, and the gooseneck will continuously tilt upward and downward or inward and outward to align with the upper, lower, inner and outer sides of the trailer, thus improving the work of the trailer. efficiency. When the gooseneck is in a suspended state, the retaining ring can be manually connected to the front tilting shaft and finally inserted into the outer extension of the tilting shaft. During the continuous descent of the gooseneck, the continuous movement of the connecting lever arch will cause the pin to bulge, which will cause the connecting plate to slide back to a fixed position. Eventually, the tractor is forced to continuously retreat, and the towing pin is connected to the towing saddle again. The entire process enables the detachable gooseneck trailer for sale in Suriname Nickli to load more cargo and operate at an appropriate height.

(2) Features of mechanically detachable gooseneck trailer.

The detachable gooseneck trailer for sale in Suriname Nickli has a complex structure and can transport a lot of goods at one time, making it very suitable for long-distance cargo transportation.
